AC500 Mesh Ceiling Raft - 1200 x 1800mm

£475.00
Availability: 20 In Stock
Sku: AC5-1218-05
Product Type: Ceiling Rafts

AC500 Series, an innovative mesh ceiling raft range that enhances spaces with its standard 600x600 expanded mesh tiles.

Crafted with precision, the cloud frames of the AC500 Series are manufactured from durable aluminium, supported by a robust 25mm T-section grid. The expanded mesh tiles seamlessly integrate into the grid, allowing easy removal for convenient access to services above when needed. Installation is made simple through a suspension method that utilises ceiling wire or galvanized angles (supplied by others).



Key Features:

  • Material: Sturdy aluminium frames ensure durability and longevity.
  • Grid: The 25mm T-section grid provides a stable framework for the expanded mesh tiles.
  • Removable Mesh Panels: Easy removal for quick access to services above.
  • Installation: Streamlined installation with a straightforward suspension method using ceiling wire or galvanised angles (supplied by others).



Applications:

  • Commercial: Enhance office spaces, meeting rooms, corridors, and conference centers with a modern mesh ceiling design.
  • Recreation and Culture: Elevate the aesthetic of museums, sport stadiums, and arenas.
  • Education: Create visually appealing ceilings in schools and libraries for an inspiring learning environment.
  • Hospitality: Introduce a contemporary touch to hotels and restaurants with the AC500 Series mesh ceiling.
  • Retail: Transform shop interiors with the sleek and versatile design of the AC500 Series.
  • Transport: Bring a modern aesthetic to airports and train stations with the mesh ceiling raft.



The AC500 Series is designed to meet the diverse needs of various settings, providing both aesthetic appeal and practical functionality. Elevate your space with the distinctive design and accessibility features of the AC500 Series mesh ceiling raft.

    Ceiling Raft Size

    Width Length
    1200mm 1800mm

    Technical Specifications

    Specification AC500
    Type Ceiling Raft
    Frame Material Aluminium
    Frame Depth 50mm
    Mesh Zircon RB35
    Mesh Tiles 6Nr. @ 590x590mm
    Mesh Open Area 60%
    Mesh Material Mild Steel
    Finish RAL 9005 (Black)
    Total Weight 10.22kg
    Fixings to ceiling (excluded) Hangers, Galv Hanging Wire

    Ceiling Raft Contents

    The AC500 Mesh Ceiling Raft is supplied in a kit confirm, which consists of:

    Mesh 6Nr. @ Zircon RB35 - 590x590mm
    Frame Upstand 2Nr. @ 1800mm
    2Nr. @ 1200mm
    T-Section

    2Nr. @ 1160mm
    1Nr. @ 575mm
    2Nr. @ 567.5mm
    Brackets 4Nr. Upstand Corner Bracket
    4Nr. Upstand to T-Section Bracket
    6Nr. T-Section to T-Section Bracket
    4Nr. T-Section Suspension Clip

    This excludes fixings from the raft to your ceiling. Fixings from raft to ceiling to be supplied by customer.
